PIC18F44J10-I/P DIP-40 40MHz Microcontroller
184,00
TL
+
VAT
220,80
TL
Notify Me When It Arrives
Notify Me When It Arrives
PIC18F44J10-I/P DIP-40 40MHz Microcontroller
Ideal for customers who need low cost, high speed and advanced serial communication peripherals. The PIC18F44J10 operates at 40 MHz at 3V and has an advanced USART with LIN and two synchronous serial ports with address masking for I2C. It is a low-cost general-purpose solution for 1k Flash endurance, emulated EEPROM, and external crystal or clock source designs for cost-sensitive applications.
Technical Specifications
| Product Code | PIC18F44J10 |
| Program Memory Type | Flash |
| Program Memory Size | 16KB (8K x 16) |
| Bus Width | 8-Bit |
| Max Clock Frequency | 40MHz |
| Data RAM Size | 1K x 8 |
| I/O Count | 32 |
| EEPROM Size | None |
| Operating Voltage Range (V) | 2.7V - 3.6V |
| Number of Pins | 40 |
