MCP1702T-3302E/MB SOT-89-3 Passive Current LDO Regulator
19,58
TL
+
VAT
23,49
TL
Notify Me When It Arrives
19,58
TL
+
VAT
23,49
TL
Add to Favorite
RecommendCommentAlarm Price
MCP1703T SOT-23-3 Passive Current LDO Regulator
MCP1702 is a family of CMOS low dropout (LDO) voltage regulators that can deliver up to 250 mA of current while consuming only 2.0 µA of quiescent current (typical). The input operating range is specified from 2.7V to 13.2V, making it an ideal choice for two to six primary cell battery powered applications, 9V alkaline and one or two cell Li-Ion powered applications.
Usage Areas
- Battery Operated Devices
- Battery Operated Alarm Circuits
- Smoke Detectors
- CO2 Detectors
- Pagers and Cell Phones
- Smart Battery Packs
- Low Quiescent Current Voltage Reference
- PDAs
- Digital cameras
- Microcontroller Power
- Solar Powered Appliances
- Consumer products
- Battery Operated Data Loggers
| Series | MCP1702T |
| Supply Voltage | 2.7V - 13.2V |
| Output Voltage | 3.3V |
| Number of Exits | 1 |
| Output Current | 250 mA Max. |
| Number of Pins | 4 |
| Package Type | SOT-89-3 |
