PIC16F84A SMD SOIC-18 8-Bit 4MHz Microcontroller

This powerful (200 nanosecond instruction execution) and easy to program (only 35 one-word instructions) CMOS Flash /EEPROM-based 8-bit microcontroller packs Microchip's powerful PIC® architecture into an 18-pin package. The same device can be used for prototyping and production, and the final application can be easily updated without removing the device from the final product via ICSP. Easily adaptable for automotive, industrial, home appliance low power remote sensors, electronic locks and security applications.

Technical Specifications

Product Code	PIC 16F84A
Program Memory Type	Flash
Program Memory Size (KB)	1.75
CPU Speed (MIPS / DMIPS)	5
SRAM (B)	68
Data EEPROM / HEF (bytes)	64
Timers	1 x 8 bit

Operating Voltage Range (V)	2 - 5.5V
Number of Pins	18

PIC16F84A Datasheet
