HLK-7688A Openwrt Router WIFI Development Kit

HLK-7688A Openwrt Router WIFI Development Kit

HLK-7688A Openwrt Router WIFI Development Kit, based on MT7688AN, developed by Hi-Link It is a development kit with a low-cost and low-power IoT module. The built-in module supports Linux, OpenWRT operating system and custom development. With its rich interface and powerful processor, smart devices and cloud services are widely used.

Kit Content

• HLK-7688A module
• 1x Adapter
• 1x Antenna
• 1x Sma to Ipex converter cable

Features

• Processor: MT7628AN
• Kernel: MIPS24KEc
• RAM: DDR 128MB
• Flash: 32MB
• Frequency : 580MHz
• 150Mbps
• 802.11b/g/n support
• 20/40 channel bandwidth
• AP,STA and AP,STA support
• Interface: SPI/SD-XC/eMMC
• Peripheral Interface: SPI,I2C,I2S,PCM,UART,JTAG,GPIO
• Linux, OpenWRT support
• 5 ​​10/100M ethernet ports

Module Pinout

Diagram
