100uF 450V Electrolytic Capacitor 25x30mm - Short Legs
23,00
TL
+
VAT
27,60
TL
Notify Me When It Arrives
Notify Me When It Arrives
100uF 450V Electrolytic Capacitor 25x30mm
An electrolytic capacitor is a polarized capacitor whose anode, or positive plate, is made of a metal that forms an insulating oxide layer through anodization. This oxide layer serves as the capacitor's dielectric. A solid, liquid, or gel electrolyte covers the surface of this oxide layer, which serves as the capacitor's cathode, or negative plate. Due to their very thin dielectric oxide layer and enlarged anode surface, electrolytic capacitors have a much higher capacitance-voltage product (CV) per unit volume than ceramic capacitors or film capacitors and can therefore have large capacitance values.
There are many applications that do not require tight tolerances and AC polarization, but do require large capacitance values. They are often used as filtering devices in various power supplies to reduce voltage ripple. When used in switching power supplies, they are often critical components that limit the usable life of the power supply, so high-quality capacitors are used in this application.
Technical Specifications
| Capacitor Type | Electrolytic Capacitor |
| Value | 100uF |
| Max. Operating Voltage | 450V |
| Dimensions | 25x30mm |
| Operating Life | 2000 Hours |
