AD822A SOIC-8 Smd OpAmp Integrated

The AD822 is a dual-precision, low-power FET input op amp that can operate from a single source from 5 V to 30 V or from a dual source from ±2.5 V to ±15 V. It features true single supply with one input voltage. The reach below the negative rail allows the AD822 to accommodate input signals below ground when in single-supply mode. Output voltage swing extends up to 10 mV of each rail, providing maximum output dynamic range.

Areas of Use

Battery-operated precision instrumentation

Photodiode preamps

Active filters

12-bit to 14-bit data acquisition systems

Medical instrumentation

Low power references and regulators

Series	AD
Supply Voltage	5V ~ 30V
Number of Channels	2 Channel
Bandwidth	1.8 Mhz
SR - Rotation Speed	3 V/us
Number of Pins	8 Pin
Package Type	SOIC-8

AD822A Datasheet
