CD105 10UH SMD Coil
CD105 SMD Power Inductor is a surface mount device. It has a ferrite drum as the core on which the wire is wound. This inductor has a magnetic shield. The moisture sensitivity level of the power inductor is 1, which means this power inductor has high moisture resistance. This type of inductor has pads for surface mounting.
Fields of Applications
Mobile phone, PDA, MP3, DSC/DVC, portable DVDTechnical Specifications:
- Material Core: Ferrite
- Inductance(µH): 10
- Tolerance(%): 20
- Current Rating (A): 1
- DC Resistance (DCR)(mΩ) at 20°c: 140
- Frequency (MHz): 2.52
- Mounting: Surface Mount.
- Operating Temperature (°c): -40 ~ 100
