LD-FK-2.4G 12-24V Wireless Dual-Door Cabinet Lighting Sensor

LD-FK-2.4G 12-24V Wireless Dual-Door Cabinet Lighting Sensor

The LD-FK-2.4G 12-24V Wireless Dual-Door Cabinet Lighting Sensor is a wireless sensor system designed to automatically control cabinet and furniture lighting based on the opening and closing of doors.

Since it utilizes 2.4G wireless communication between the sensor unit and the receiver connected to the LED circuit, there is no need to run additional control cables from the door sensor to the LED driver. Equipped with a rechargeable lithium battery, the sensor can be conveniently mounted onto a cabinet door or the cabinet frame itself.

Unlike the single-door version, this model is designed to monitor the status of two separate doors. When either one or both doors are opened, the corresponding magnet moves away from the detection zone, triggering the lights to turn on.

For the lighting to turn off, both doors must be in the closed position, and both magnets must be within the sensor's detection range.

Note: The sensor communicates wirelessly with its own dedicated receiver.

Specifications

• Supply Voltage: 12-24VDC
• Wireless Communication: 2.4G RF
• Control Range: 10m
• Control Mode: Single Door
• Protection Class: IP20
• Equipped with a rechargeable lithium battery
• Load: 12V 60W / 24V 100W
• Sensor Power Supply: 5V
• Charging Interface: Type-C
