LD-FK-2.4G 12-24V Wireless Single-Door Cabinet Lighting Sensor

LD-FK-2.4G 12-24V Wireless Single-Door Cabinet Lighting Sensor

The LD-FK-2.4G 12-24V Wireless Single-Door Cabinet Lighting Sensor is a wireless sensor system designed to automatically control cabinet and furniture lighting based on the opening and closing of a door.

Since it utilizes 2.4G wireless communication between the sensor unit and the receiver connected to the LED circuit, there is no need to run additional control cables from the door sensor to the LED driver. Equipped with a rechargeable lithium battery, the sensor can be easily mounted onto a cabinet door or the cabinet frame.

In this single-door model, the sensor detects the position of a magnet placed on the door. When the door is closed, the magnet is positioned within the sensor's detection zone, causing the lighting to turn off.

When the door is opened, the magnet moves away from the sensor, and the lighting turns on automatically.

Note: The sensor communicates wirelessly with its own dedicated receiver.

Specifications

• Supply Voltage: 12-24VDC
• Wireless Communication: 2.4G RF
• Control Range: 10m
• Control Mode: Single Door
• Protection Class: IP20
• Equipped with a rechargeable lithium battery
• Load: 12V 60W / 24V 100W
• Sensor Power Supply: 5V
• Charging Interface: Type-C
