ULN2003 DIP16 Integrated
ULN2001, ULN2002, ULN2003 and ULN 2004, seven open collector Darlington pairs each with common emitters high voltage, high current Darlington arrays. Each channel is rated for 500 mA and can withstand peak currents of 600 mA. Suppression diodes are included for inductive load driving, and the inputs are fixed opposite the outputs to simplify board layout.
Uses
- Relay Drivers
- Step and DC Brush Motor Drivers
- Led Drivers
- Display Drivers
- Line Drivers
| Series | ULN |
| Collector-Emitter Voltage | 50V max |
| Collector Current Max | 0.5A |
| Number of Pins | 16 |
| Package Type | DIP-16 |
