ZX-08CDEN 10-Frequency RFID Writer/Reader/Copier

ZX-08CDEN 10-Frequency RFID Writer/Reader/Copier

The ZX-08CDEN 10-Frequency RFID Writer/Reader/Copier is a portable RFID reader-writer and programming device designed to read RFID cards, key fobs, and tags operating at various frequencies, as well as to program compatible cards and duplicate them for authorized systems.

It supports a total of 10 different operating modes: 125kHz, 250kHz, 375kHz, 500kHz, 625kHz, 750kHz, 875kHz, 1MHz, HID-125kHz, and 13.56MHz IC mode. This versatility allows it to be used in access control, personnel tracking, and electronic identification systems that utilize different RFID technologies.

For portable use, the device can be powered by four AAA batteries or via a USB connection.

Thus, it can be used for fieldwork in addition to desktop applications.

Batteries are not included.

Specifications

• Supported Frequencies: 125kHz / 250kHz / 375kHz / 500kHz / 625kHz / 750kHz / 875kHz / 1MHz / HID-125kHz / 13.56MHz IC
• Supported Card Reading: EM4100 / EM4200 / MClassic / UID / HID 1386 / HID 1326 / NTAG203
• Supported Card Writing: T5577 / EM4305 / HID 1386 / HID 1326 / UID
• Display: 2.8-inch / 7.1 cm color screen
• Voice Notification: English
• PC Connection: USB
• USB Operating Voltage: 5V DC
• Reading Distance: Approx. 1–8 cm
• Operating System: Windows XP / 7 / 10 / 11
• Portable Power: 4 × AAA batteries
• USB Cable Length: Approx. 1 meter
• Operating Temperature: -10°C to +50°C
• Body Type: Handheld
