DELTECH I/Q-8 12-24V 4A Rail Type DC Motor Driver

DELTECH I/Q-8 12-24V 4A DIN Rail Type DC Motor Driver

The DELTECH I/Q-8 12-24V 4A DIN Rail Type DC Motor Driver is a DC motor controller with a microprocessor-based system that allows precise speed control and external direction control. It has instantaneous direction change capability and can withstand a peak current of 40A for 4ms.

User Manual

Inputs

• Power Supply
• COM
• Input

Outputs

• PNP Output

General Features

• PLC CONTROL
• SENSOR AND ANALOG CONTROL
• PNP AND NPN INPUT
• 1 KHZ PNP OUTPUT
• Peak Current 40A for 4ms
• Mosfet Technology
• Mono block heatsink
• Input isolation 3700Vrms 20mA
• Slim and compact design

Specifications

• Input Voltage: 12-24VDC
• Continuous Output Current: 12V DC-- 8A / 24V DC --4A
• Operating Temperature: -55 °C to +110 °C
• Response Time: 1ms
• Mounting Type: DIN Rail Mount
• Dimensions: 32x87x114mm (W*H*D)
• Device Weight: 150 grams

SAFETY INSTRUCTIONS

• Do not connect or disconnect cables from terminals while the device is powered.
• Make sure the cable connections are correct as specified on page 3. The device will not be covered under warranty for damage caused by incorrect connections.
• Avoid operating the device in humid conditions.
• It is recommended to use the device in environments with proper air circulation.
• Use a power supply or battery that provides the required current for the valve, brake, or motor being u
