HDMI 4K 120M KVM Extender - HDMI+USB+IR To Cat5E/6, This extender supports signal transmission up to 120 meters. Supports 4K / Full HD1080P, 3D, HDCP, 2K image signals.

USB Cable transfers Signal, IR Control Command signal, does not cause signal loss, has Easy Use and Installation with 5V / 1A Power Adapter.

Package Content

• Transceiver
• 2x Adapter
• 2x IR eyes
• USB to USB cable

Features

• Supported Signal Distance: 120m
• HDMI Input: 4k/1080p/720p/576p/576i/480p/480i
• HDMI Output: 4k/1080p/720p/576p/576i/480p/480i
• Maximum Banwidth: 340MHz
• Maximum Baud Rate: 3x3.4Gbps
• Input Video Signal: 0.5~1.5Volts p-p
• Output Video Signal: 5Volts p-p (TTL)
• TX Maximum Operating Current: 350mA
• RX Maximum Operating Current: 200mA
• TX Weight: 499g
• RX Weight: 494g
• Size: 163x87x24mm
