LM2904P DIP-8 OpAmp IC

It consists of two independent, high-gain, frequency-compensated operational amplifiers designed to operate from a single source over a wide voltage range. Operation from split sources is possible as long as the difference between the two sources is 3 V to 26 V (3 V to 32 V for V-suffix devices) and VCC is at least 1.5 V more positive than the input common mode voltage. The low supply current drain is independent of the magnitude of the supply voltage.

Applications include converter amplifiers, dc amplification blocks, and all conventional operational amplifier circuits that can now be more easily implemented in single-supply voltage systems. For example, these devices can be powered directly from the standard 5 V supply used in digital systems and easily provide the necessary interface electronics without an additional ±5 V supply.
