RF Microwave DC Splitter HF Bias Tee 0.2-180mhz

This perfect fit for broadband amplifier filter module will reduce the difficulty of operation. The wide frequency range from 0.2 to 180 MHz provides very practical, effective clutter filtering. RF power supply from active antenna will greatly improve work efficiency with high stability.

Bias tee module is low with 0.1dB at 1MHz and 0.4dB at 100MHz loss and provides promising signal quality. Adopting high-frequency magnetic ring, communication data is injected through the RF terminal.

Technical Specifications

Item Type: Bias Tee Module

Frequency Range: 0.2 -180MHz

Insertion Loss: 0.1dB at 1MHz, 0.4dB at 100MHz.

Maximum Voltage: 30V

Maximum Current: 3A

RF Connector: SMA-K

System Impedance: 50 ohm

Connection

RF: Radio frequency signal terminal (this port can only transmit radio frequency signals)

RF+DC: RF DC bias (this port can transmit RF and DC bias)

GND-: Common ground terminal for DC power supply< /DIV>

VCC+: Power supply terminal of DC power supply
