The TL Smoother V1.0 3D Printer Filter Module is an 8-diode filter module designed to be connected between the stepper motor driver and the stepper motor in 3D printers, helping to smooth out motor movements. It helps reduce vibrations, motor noise, and surface irregularities that can occur, particularly in systems using stepper motor drivers like the A4988 and DRV8825.

Current fluctuations and driver output characteristics during stepper motor operation can cause artifacts such as "salmon skin," zebra stripes, or similar fine patterns to appear on the print surface. By smoothing signal transitions through its diode-based circuitry connected to the motor phase outputs, the TL Smoother module helps the stepper motor operate more stably.

Specifications

• Diode: S3G
• Number of Diodes: 8
• Motor Type: Bipolar stepper motor
• Connection Channel: 4-line / 2-phase stepper motor
• Input Connection: Stepper motor driver output
• Output Connection: Stepper motor
• Connection Type: 4-pin
• Operation Mode: Passive filter
