EC Water Conductivity Sensor and Transmitter Module - RS485 0-4400µS
The EC Water Conductivity Sensor and Transmitter Module (RS485 0-4400µS) is an EC transmitter and electrode system featuring an RS485 Modbus RTU output and a measurement range of 0–4400 µS/cm, designed for the continuous measurement of the electrical conductivity of liquids.
EC (Electrical Conductivity) refers to a liquid's ability to conduct electric current. Generally, as the concentration of dissolved ions and salts in the water increases, the conductivity value also rises.
Specifications
- Power Supply: DC 12–24V
- Measured Parameter: Electrical conductivity
- EC Measurement Range: 0–4400 µS/cm
- Output: RS485
- Protocol: Modbus RTU
- Default Modbus Address: 1
- Measurement Accuracy: ≤ ±2% F.S. class
- Measurement Unit: µS/cm
- Data Retention During Power Loss: Yes
- Overcurrent Protection: Yes
- Overvoltage Protection: Yes
- Communication System: RS485 two-wire differential communication
- PLC / HMI Compatibility: Systems supporting Modbus RTU
