LP-24-J19SX-03-401 19-Pin Waterproof Connector - Female

It is a 19-pin female connector for power applications. Compatible with 20-22 AWG cable. It has a snap design for a reliable connection. Built to withstand the demands of industrial applications.

The LP series is one of the best-selling waterproof connector series made from high-performance engineering plastics. Quick plug design allows one-handed plug/remove. It has gold plating technology that is resistant to corrosion and suitable for high and low temperatures. LP-24 series connectors are widely used in various harsh environments and situations such as audio-visual equipment, medical equipment, industrial control, inspection and measurement due to their small size, flexible operation and automatic plug-in/disconnect. Compact components, simple operation, fast and stable connection, IP67-rated outdoor waterproof performance.

LP-24-C19PE-01-001 19-Pin Waterproof Connector.

Technical Specifications

Gold-plated contacts for increased corrosion protection
PBT shell
High temperature and pressure resistance
IP65/67 rating when connected
Number of Pins: 19
Cable Size: 20-22 AWG
Diameter Range: 9-14mm
Contact Diameter: 1mm
Rated Current: 5A

Operating Voltage: 250V

Contact Resistance: <5mOhm
Withstand Voltage: 1500V
Operating Temperature: -40 C to 80 C (-40 F to 176 F)
Enclosure Material: High Performance Plastic
