RS-O3-N01-2-100P-2 0-100ppm RS485 Wall-Mounted Ozone Sensor

RS-O3-N01-2-100P-2 0-100ppm RS485 Wall-Mounted Ozone Sensor

The RS-O3-N01-2-100P-2 0-100ppm RS485 Wall-Mounted Ozone Sensor is a fixed-mount industrial gas sensor designed to continuously measure O3 (ozone) concentrations in ambient air. Thanks to its wall-mountable design, it is suitable for long-term monitoring applications in production areas, laboratories, facilities utilizing ozone generators, and air quality monitoring systems.

It features an RS485 communication output and can be integrated into standard Modbus RTU-based automation systems.

Thus, sensor data can be monitored remotely via PLCs, HMIs, computers, data loggers, or RS485-enabled control systems.

Specifications

• Measured Gas: O3 / Ozone
• Measurement Principle: Electrochemical
• Output: RS485
• Communication: Modbus RTU
• Supply Voltage: 10–30V DC
• Power Consumption: Approx. 0.1W
• Measurement Range: 0–100 ppm
• 0–100 ppm Resolution: 0.1 ppm
• Accuracy: ±6% FS
• Data Update Interval: 1 second
• Response Time: ≤180 seconds
• Warm-up Time: ≥5 minutes
• Repeatability: ≤2%
• Zero Drift: ±1% FS
• Long-term Stability: ≤7% signal value / year
• Operating Temperature: -10°C to +55°C
• Operating Humidity Range: 15–90% RH, non-condensing
• Operating Pressure: 91–111 kPa
• Mounting Type: Wall mount
• Continuous
Monitoring: Suitable
