TPS305 30V 5A Adjustable DC Power Supply

TPS305 is a high precision DC power supply that can output up to 5A between 0-30V. There is an adjustment encoder on the product that allows you to adjust voltage and current. When you press these encoders, which allow adjustment, the adjustment sensitivity can change. There is a V/A button on the power supply. This button switches between current and voltage. Whichever we choose, the adjustment encoder adjusts that value.

The product does not give direct output when it is turned on. The exit button must be pressed for it to output. When the green light turns on, the product gives output. Additionally, there is an OCP short circuit overcurrent protection button on the product. OCP is a function that protects against overcurrent situations in short circuit situations.

TPS305 is lighter than old-style power supplies, thanks to its modern design and circuit structure. It also has USB and Type-C outputs that allow charging phones and similar 5V devices.

Features:

Model: TPS305
Input: 220V AC (outlet)
Output Voltage: 0-30.00V
Current: 0-5.00A
Resolution: 0.01V / 0.001A
Accuracy: 0.5%±20
OVP: High Voltage Protection
OCP: Overcurrent Protection
OPP : High Power Protection
OTP: High Temperature Protection
SCP: Short Circuit Protection
Dimension: 210x145x80mm
Weight: 1.2kg

Product Content:

TPS305 Power Supply
AC Power Cord
English User Manual
2 Crocodile Probe Cables
