INA826AID SOIC-8 Smd Amplifier Amplifier Integrated

INA826 offers extremely low power consumption and a very wide range of single source or dual It is a cost-effective instrumentation amplifier operating in the source range. A single external resistor adjusts the gain anywhere from 1 to 1000. The device offers excellent stability over temperature even at G > 1 as a result of the low gain drift of only 35 ppm/°C (maximum).

INA826, Optimized to provide excellent common mode rejection ratio of over 100 dB (G = 10) at frequencies up to 5 kHz. At G = 1, the common-mode rejection ratio exceeds 84 dB over the entire input common-mode range from negative supply to positive supply up to 1 V. Using a rail-to-rail output, the INA826 is an excellent choice for low-voltage operation from a 3 V single supply as well as dual supplies up to ±18 V.

Analog input module

Stream transmitter

battery test

LCD test

Electrocardiogram (ECG)

surgical equipment

Process analytics (pH, gas, concentration, force and humidity)

Circuit breaker (ACB, MCCB, VCB)
