LTC3780 DC-DC 6-30V to 1.5V-30V 10A Boost-Load Regulator Module

LTC3780 DC-DC 6-30V to 1.5V-30V 10A Boost-Load Regulator Module

The LTC3780 DC-DC 6-30V to 1.5V-30V 10A Boost-Load Regulator Module is a new technology that uses special power MOSFETs with very low on-state resistance instead of rectifier diodes to reduce synchronous rectification losses. It can greatly increase the efficiency of DC/DC converters and prevents dead voltage caused by Schottky barrier voltage.

It allows you to adjust the input voltage from 6V-30V to 1.5V-30V. The output current is a maximum of 10 Amperes.

If it will be used for a long time, a current of 7 Amperes should be drawn. Otherwise, it is recommended to use a cooling fan.
It is suitable for use as a charging module due to its current limiting feature.
The power supply is an automatic high-efficiency voltage regulator. Regardless of the input voltage value, it keeps the output voltage constant.
Suitable for use as Solar Energy Panels.
Since the output current can be stabilized, it allows use as a battery charging circuit.
For example, set the output to 12V, then changing the input voltage in the range of 6-30V will result in a constant output voltage of 12V.

Features

• Input Voltage: 6-30VDC
• Output Voltage: 1.5-30VDC
• Output Power: 80W for extended periods (130W peak power)
• We recommend strengthening the cooling for power levels above 80W
• Short Circuit Protection
• Dimensions: 77x45x12mm
