AWG mm2 Conversion Table | AWG Current Table
AWG to mm2 conversion table, awg current table, what do awg values mean? In our blog post, we will explain what awg values mean, their equivalents in mm2, and current values.
AWG is a widely used expression in cables. Therefore, there is a lot of misinformation about this abbreviation circulating. We will explain this term to eliminate misconceptions and to inform those who are curious. We will share the AWG to mm2 conversion table and the awg current table with you.
What is AWG
AWG is actually an abbreviation in English. It stands for American Wiring Gauge. In other words, we can say American Wiring Measurement Unit. There are several misconceptions about these values. AWG is definitely not a type of cable. So when you go to a place that sells cable products, you should not say that you want awg cable. :)
Another misconception is about cable thicknesses. As the related cable value increases, the cable thickness does not increase as thought. As the AWG value decreases, the thickness of the cable increases. As it increases, the cable becomes thinner. For example, a 16 AWG cable is thinner than a 12 AWG cable.
AWG to mm2 Conversion Table
AWG to mm2 Conversion Table is a very useful table especially when buying cables. Although these values are preferred in electronic standards most of the time, in our country, cable needs are mostly known in mm. Therefore, one of the most frequently asked questions to us is about awg to mm2 conversion values. You can see all the equivalents in mm2 in the table below.
| AWG | mm2 |
|---|---|
| 30 | 0.05 |
| 28 | 0.08 |
| 26 | 0.14 |
| 24 | 0.25 |
| 22 | 0.34 |
| 20 | 0.52 |
| 18 | 0.82 |
| 16 | 1.31 |
| 14 | 2.08 |
| 12 | 3.31 |
| 10 | 5.26 |
| 8 | 8.37 |
| 6 | 13.3 |
| 4 | 21.15 |
| 2 | 33.63 |
| 1 | 42.41 |
| 0 | 53.47 |
| 00 | 67.43 |
| 000 | 85.03 |
